30
SWITCH ASSEMBLY, DOOR LOCK
WHEN FOREIGN MATERIAL IS STUCK BETWEEN DRUM AND TUB
Take apart the cabinet cover clamp and release
the gasket.
Unscrew 2 screws holding the door lock.
Disconnect the door lock from the wiring connector.
Remove the heater.
Remove the foreign material (wire, coin and others) by
inserting a long bar through the hole.
Downloaded From WashingMachine-Manual.com Manuals

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the LG WD-10480T and is the answer not in the manual?

LG WD-10480T Specifications

General IconGeneral
Power consumption (typical)2100 W
Water consumption per cycle69 L
Energy consumption washing per cycle1.2 kWh
Display typeLED
Loading typeFront-load
Product colorWhite
Door opening angle180 °
Appliance placementFreestanding
Washing classA
Power requirementsAC 220 - 240V, 50Hz
Drum capacity7 kg
Delay start (max)19 h
Spin-drying classB
Maximum spin speed1000 RPM
Delayed start timerYes
Number of washing programs16
Weight and Dimensions IconWeight and Dimensions
Depth550 mm
Width600 mm
Height842 mm
Weight65000 g
