LG WD-10480T User Manual

27
Take apart the cabinet gasket clamp.
Unscrew 2 screws from the cabinet cover.
Open the lower cover cap and unscrew 1 screw inside.
Take apart the lower cover.
Disassemble the cantrol panel. (refer to the page 25)
Unscrew all the screws on the upper and lower sides
of the cabinet cover.
Take apart the tub gasket clamp.
Make sure that the drain hole of the gasket is put
beneath when reassembling the gasket.
Refer to the arrow mark on the tub cover.
GASKET ASSEMBLY
Downloaded From WashingMachine-Manual.com Manuals

LG WD-10480T Specifications

General

Power consumption (typical)	2100 W
Water consumption per cycle	69 L
Energy consumption washing per cycle	1.2 kWh
Display type	LED
Loading type	Front-load
Product color	White
Door opening angle	180 °
Appliance placement	Freestanding
Washing class	A
Power requirements	AC 220 - 240V, 50Hz
Drum capacity	7 kg
Delay start (max)	19 h
Spin-drying class	B
Maximum spin speed	1000 RPM
Delayed start timer	Yes
Number of washing programs	16

Weight and Dimensions

Depth	550 mm
Width	600 mm
Height	842 mm
Weight	65000 g
