14
TRANSFORMATION OF PRODUCT
ENG
ENGLISH
TRANSFORMATION OF PRODUCT
Reassembly for 55-in Multi-Vision
- The picture may differ from the actual product.
1
Remove the screws (32 pieces) shown in the red dotted-line circle in the figure below.
2
If you move the bracket in other directions, you can see all of the screw holes that are in different loca-
tions. Reassemble the bracket by fastening the screws (32 pieces).
WM-L640V
Changed location
Original location
Changed location
To Next Page
