37
SPECIFICATIONS
ENGLISH
SPECIFICATIONS
Model WM1388H* / WM1385H*
Description Front-loading washing machine
Electrical requirements 120 VAC @ 60 Hz
Dimensions 60.96 cm(W) x 64.0 cm(D) x 85.09 cm(H)
,
114.3 cm (D, door open)
24"(W) x 25.20"(D) x 33.5"(H)
,
45" (D, door open)
Capacity 2.3 cu.ft (IEC2.6 cu.ft) (Dry linen capacity 9 kg)
Net weight 67 kg (148 lbs)
Max. spin speed 1400 rpm max
Max. water pressure 20 – 120 psi (138 – 827 kPA)
Problem Possible Causes Solutions
Banging noise when
washer is filling with
water (Water Hammer)
y
Plumbing in the home moves or
flexes when the water valves in the
washer shut off.
y
Household water supply pressure is
very high.
y
Water hammer is not caused by a
defect in the washer. Install water
hammer arrestors (purchased
separately at hardware or home
improvement store) between the fill
hose and the washer for best results.
y
Adjust household water supply
regulator to a lower pressure or
contact a plumber to have a regulator
installed.
Strange odors coming
from washer
y
First time using washer
y
Buildup of dirt on gasket or drum,
dirty or clogged drain pump filter,
kinked or clogged drain hose
y
Smell comes from the rubber
attached to the washer door. It will
eventually dissipate after first couple
of wash cycles.
y
Periodically clean the gasket. Mold and
foreign substances inside the gasket
may produce mildew or musty smells.
y
Clean the drain pump filter regularly.
Foreign substances on the drain
pump filter may produce mildew or
musty smells.
y
If the drain hose is not installed
properly, the odor may be emitted
because of a backflow of drainage
into the tub. Make sure that the drain
hose is not kinked or clogged.
Odor
y
This odor is caused by the rubber
attached to the washing machine.
y
If the rubber door gasket and door
seal area are not cleaned regularly,
odors can occur from mold or
foreign substances.
y
Odors can occur if foreign substances
are left in the drainage pump filter.
y
Odors can occur if the drainage hose
is not properly installed, causing
siphoning (water flowing back inside
the washing machine).
y
Using the dry function, odors can
occur from lint and other laundry
matter sticking to the heater. (Dryer
model only)
y
A particular odor can occur from
drying wet clothes with hot air.
(Dryer model only)
y
It is the normal odor of new rubber
and will disappear after the machine
has been run a few times.
y
Be sure to clean the gasket and
door seal regularly and check under
the door seal for small items when
unloading the washer.
y
Be sure to clean the drainage pump
filter regularly.
y
When installing the drainage hose, be
sure that it doesn’t become kinked or
blocked.
y
This is not a malfunction.
y
The odor will disappear after a short
while.
To Next Page
