LG WM1815CS - 9 Disassembly Instructions; Control Panel Assembly

26
9. DISASSEMBLY INSTRUCTIONS
TOP PLATE ASSEMBLY
CONTROL PANEL
ASSEMBLY
DRAWER
CONTROL PANEL ASSEMBLY
Be sure to unplug the machine out of the outlet before disassembling and repairing the parts.
Unscrew 2 screws on the back of the top plate.
Pull the top plate backward and upward as shown.
Disconnect the connectors from the Main PWB
Assembly
Pull out the drawer and unscrew 2 screws.
Lift the left side of the Control Panel Assembly and
pull it out.
