32
Unscrew the 4 screws from the back cover.
Unscrew the single screw from the lower-right
side of the cabinet.
Disconnect the connector from PWB Harness.
Disassemble the Back cover.
Unscrew a screw from the Tub.
Unplug the white connector from the thermistor.
Pull it out by holding the bracket of the
thermistor.
CONNECTOR
To Next Page
