LGMG AS0607 - Turning and Turning Protection

USER MANUAL - SS0407E / SS0507E / SS0607E / AS0607 / AS0607W / AS0607WE / AS0607E / AS0608 / AS0608E
19
• The direction of travel and speed can be controlled by moving the lever.
• The "high speed" (high speed) or "low speed" (low speed) mode can only be selected when the platform is in
transport position. However, if the platform is raised and the exit protector is activated, the machine only
operates in "acceleration after lifting" mode.
• If the platform is overloaded, the lifting function is not permitted.
• If the internal part of the motor control is overheated, the platform is delayed.
• The brake shall be applied in a non-moving mode.
Turning and turning protection
1) The key switch must be put in platform mode.
2) Steering can only be controlled via the left and right buttons on the top of the lever on the PCU.
3) If you want to steer the machine, make sure you select the drive mode and you select the dead man switch
on the lever.
Other controls
1) When the platform raises or runs, the timer is started on the chassis.
2) Two LEDs on the PCU are used to indicate the battery status, error code and settings data.
Low battery operation
1) The charge status of the battery depends on the battery level set by the operator. The battery charge bar is
displayed on the PCU.
2) Normal movement can be enabled if there are two or more battery charging bars.
3) The travel speed is reduced if there is only one battery charger bar.
4) The brake shall be applied in a non-moving mode.
Chapter 4 - Operation
