USER MANUAL - SS0407E / SS0507E / SS0607E / AS0607 / AS0607W / AS0607WE / AS0607E / AS0608 / AS0608E
33
Chapter 8 - Function test
8.7 Test of auxiliary lower function
1) Push the platform lift and lower switch up to raise the platform approximately 60 cm.
2) Pull out the emergency lowering control button on the left front side of the machine. Result: the platform
goes down. The lowering alarm doesn't go off.
3) Engage the ignition switch on the platform controls.
8.8 Platform control test
1) Push the red Ground Emergency Stop button to the "OFF" position. Result: all functions are not enabled.
2) Set the red emergency stop button to the "ON" position. Result: The LED indicator light of the data diagnosis
device lights up.
8.9 Klaxon test
1) Press the klaxon button.
2) Result: the klaxon sounds.
8.10 Test of lift/lower function and initiate function
1) Do not press the dead man switch on the control lever.
2) Slowly move the control lever according to the blue arrows, then move the yellow arrows.
Result: all functions are not enabled.
3) Press the lift function selection button.
4) Press the dead man switch on the control lever.
5) Slowly move the control lever according to the blue arrows. Result: the platform goes up.
The exit protector is unfolded.
6) Release the platform control lever Result: the platform stops rising.
7) Press the dead man's button. Slowly move the control lever according to the yellow arrows.
Result: the platform goes down. When the platform goes down, the lowering alarm goes off.
8.11 Turning test
Notice: stand on the platform and look at the steering wheels of the machine when testing the steering and
the driving function.
1) Press the drive function select button, the indicator light will illuminate.
2) Press the dead man switch on the control lever.
3) Press the toggle switch on the top of the lever in the direction indicated by the
arrows on the control panel. Result: the steering wheel moves in the direction indicated by
the arrows on the driving chassis.
8.12 Test of driving and braking function
1) Press the dead man switch on the control lever.
2) Slowly move the control lever in the direction of the up arrows on the control panel until machine moves and
return the lever to the centre. Result: the machine moves in the direction of the arrows on the control panel
and stops.
Notice: the brake must be able to stop the machine at any level.
