Chapter 8 - Function test
8.13 Test of driving and braking function
1) Press the lift/stop/lower switch and the indicator light will illuminate. Press the dead man switch on the lever
to lift the platform until it reaches a height of about 2 m above the ground.
Result: the exit protector is extended.
2) Press the drive function select button, the indicator light will illuminate.
3) Press the dead man switch on the control lever and slowly move the control lever to complete the driving
position. Result: the driving speed of the platform will not exceed 0.5 km / h when the platform is in
transport status. Result: the driving speed of the platform is higher than 0.5 km / h when the platform is
raised. Mark the machine immediately and stop the operation.
8.14 Test for the operation of the inclination sensor
Note: This test must be performed with a platform control on the ground. Don't stand on the platform.
1) Lower the platform completely.
2) Drive the two wheels on the same side to a 3.5 x 20 cm buffer.
3)
Raise the platform at least 2 m. Result: the platform stops moving and the slope alarm sounds 120 times a minute.
4) Move the control lever upwards according to the arrows and then move the arrows downwards.
Result: the driving function is switched off in every direction.
5) Lower the platform and drive the machine away from the obstruction.
8.15 Test of Exit protector
Notice: if the platform is raised, the exit protector is automatically folded out. The exit protector can start
another limit switch to enable the machine to be operated.
If it is not possible to fold out the exit protector, the alarm will sound and the machine will stop driving at
the same time.
1) Raise the platform. Result: when the platform is raised 2 m from the ground, the exit protector unfolds.
2)
Press rst on one side of the exit protector and then on the other side. Result: the exit protector doesn't move.
3) Lower the platform. Result: the exit protector returns to the folding position.
4) Apply a 3.5x20 cm buffer block under the exit protector made of wood, or a similar material.
Raise the platform. Result: when the platform is raised 2 m from the ground, the alarm sounds. In that
case, the driving function is deactivated.
5) Lower the platform and remove the 3.5x20 wooden block.
