LI-COR LI-820 - Page 75

Section 5
Maintenance 5-3
Remove these
4 screws
5. The source and detector housings (with attached circuit boards) can now be removed.
The bench will appear as shown below. It is a good practice to replace the O-rings when
cleaning or replacing the optical path.
O-ring
Top View
End View
