Appendix A
A-2 Appendix A
Internal Optical Bench Volume: 14.5 mL.
Signal Averaging: 0-20 seconds (user-selectable)
Source Life: Approximately 18,000 hours.
Output Signals: 0 – 5V, 0 – 2.5V, 4 – 20 mA
DAC Resolution: 14-bits across specified range
Power Requirements: Input Voltage 12-30 VDC (low power light comes on at approximately 10 VDC)
1.2A @ 12V (14W) maximum during warm-up with heaters on.
0.3A @ 12V (3.6W) average after warm-up with heaters on.
Warm-Up Time: 1.5 hours
Operating Temp Range: -25
°C to +45
°C
Relative Humidity Range: -25 to 45 °C, 0 to 95% RH, Non-Condensing
Dimensions: 8.75” 6” 3” (22.23 15.25 7.62 cm)
Weight: 2.2 lbs. (1.0 kg)
* Specifications subject to change without notice.
