Liberty Pumps Omnivore LSG202M User Manual

©Copyright 2012 Liberty Pumps Inc. Tous droits réservés - 2 -
SECTION 1 RENSEIGNEMENTS GÉNÉRAUX ------------------------------------------------------------------- 3
SECTION 2 INTRODUCTION--------------------------------------------------------------------------------------------4
SECTION 3 INSTALLATION MÉCANIQUE ------------------------------------------------------------------------ 4-6
SECTION 4 RACCORDEMENT ÉLECTRIQUE -------------------------------------------------------------------- 6-8
SECTION 5 FONCTIONNEMENT ------------------------------------------------------------------------------------ 9
TABLEAU DE DÉPANNAGE --------------------------------------------------------------------------- 10
FEUILLET D'INSTALLATION DU PANNEAU ------------------------------------------------------ 11
SCHÉMA D’INSTALLATION TYPE ------------------------------------------------------------------- 12
COURBES DE RENDEMENT -------------------------------------------------------------------------- 13
SECTION 6 GARANTIE -------------------------------------------------------------------------------------------------- 14
Table des matières

Liberty Pumps Omnivore LSG202M Specifications

General

Model	LSG202M
Horsepower	2
Voltage	115/230
Construction Material	Cast Iron
Housing Material	Cast Iron
Float Switch Included	Yes
Thermal Overload Protection	Yes
Warranty	3 Years
Discharge Size	2
Motor Type	Oil-filled
Maximum Solids Handling	2
Phase	Single-Phase
