Liebert CBH 017 - Page 15

12
SBH -- R 407C
Size 017 020 023 025 028 030 032
P ower supply --- 400 V / 3 Ph / 50 Hz
OA
(1)
FLA
LRA
Compressors power input
(1)
Compressors nominal current
(1)
Compressor max. current
A
A
A
kW
A
A
111
151
291
57.1
100
35
123
181
346
66.3
112
50
145
215
380
78.5
130
50
165
253
454
90.2
150
69
187
291
492
103.8
172
69
203
301
549
111.5
184
72
229
307
555
128.6
210
72
Fan power input
Fan nominal current
Fan max. current
kW
A
A
1.9
3.8
4.0
Std. head pressure pump model (Opt.)
Std. head pressure pump motor max. power
Std. head pressure pump max. current
High head pressure pump model (Opt.)
High head pressure pump motor max. power
High head pressu re pump max. current
---
kW
A
---
kW
A
65---260/2
4.0
8.00
65---340/2
5.5
11.20
65---340/2
5.5
11.20
65---410/2
7.5
15.20
65---410/2
7.5
15.20
65---460/2
11.0
21.40
Electrical cable section (min.) mm
2
70 95 120 150 185 185 185
(1) Outdoor air temperature 35ûC; 30% glycol water mixture; water inlet/outlet temperature 15/10ûC
SLH -- R 407C
Size 017 020 023 025 028 030 032
P ower supply --- 400 V / 3 Ph / 50 Hz
OA
(1)
FLA
LRA
Compressors power input
(1)
Compressors nominal current
(1)
Compressor max. current
A
A
A
kW
A
A
111
147
287
60.3
104
35
125
177
342
70.4
118
50
145
209
374
82.7
136
50
165
247
448
95.6
156
69
178
288
489
100.4
166
69
198
294
542
112.7
186
72
222
300
548
129.4
210
72
Fan power input
Fan nominal current
Fan max. current
kW
A
A
1.0
2.3
2.4
Std. head pressure pump model (Opt.)
Std. head pressure pump motor max. power
Std. head pressure pump max. current
High head pressure pump model (Opt.)
High head pressure pump motor max. power
High head pressu re pump max. current
---
kW
A
---
kW
A
65---260/2
4.0
8.00
65---340/2
5.5
11.20
65---340/2
5.5
11.20
65---410/2
7.5
15.20
65---410/2
7.5
15.20
65---460/2
11.0
21.40
Electrical cable section (min.) mm
2
70 95 120 150 185 185 185
(1) Outdoor air temperature 35ûC; 30% glycol water mixture; water inlet/outlet temperature 15/10ûC
SQH -- R 407C
Size 017 020 023 025 028 030
P ower supply --- 400 V / 3 Ph / 50 Hz
OA
(1)
FLA
LRA
Compressors power input
(1)
Compressors nominal current
(1)
Compressor max. current
A
A
A
kW
A
A
106
146
286
57.9
100
35
118
176
341
67.3
112
50
141
207
372
81.8
134
50
161
245
446
94.2
154
69
177
283
484
102.5
170
69
205
289
537
121.9
198
72
Fan power input
Fan nominal current
Fan max. current
kW
A
A
0.75
1.4
1.5
Std. head pressure pump model (Opt.)
Std. head pressure pump motor max. power
Std. head pressure pump max. current
High head pressure pump model (Opt.)
High head pressure pump motor max. power
High head pressu re pump max. current
---
kW
A
---
kW
A
65---260/2
4.0
8.00
65---340/2
5.5
11.20
65---340/2
5.5
11.20
65---410/2
7.5
15.20
65---410/2
7.5
15.20
65---460/2
11.0
21.40
Electrical cable section (min.) mm
2
70 95 120 150 185 185
(1) Outdoor air temperature 35ûC; 30% glycol water mixture; water inlet/outlet temperature 15/10ûC
• Nominal power supply = 400 V; 3 P h; 50 Hz
• Nominal power supply tolerance = 400 V ±10 %
• Max. voltage unbalance = 3 %
• The cables have to be sized in compliance with local standards and according to the type and characteristics of installation. Suggested cables section are re-
ferred to PVC insulation with a max. working temperature of 70ûC and an ambient temperature of 30ûC.
