Tab. 7 --- Operating limits
CBH -- R 407C
Size 017 020 023 025 028 030 032
Working Range
Max. outdoor air temperature
(1)
ûC
45.0 41.5 45.0 43.0 44.0 45.0 43.5
Safety Device Settings
High pressure switch
(1)
High pressure safety valve
Low pressure switch
Barg
Barg
Barg
26.0
29.0
2.8
(1)
With nominal air flow; water flow outlet at 7ûC ; full load
CLH -- R 407C
Size 017 020 023 025 028 030 032
Working Range
Max. outdoor air temperature
(1)
ûC
45.0 41.5 45.0 43.0 45.0 42.0 41.5
Safety Device Settings
High pressure switch
(1)
High pressure safety valve
Low pressure switch
Barg
Barg
Barg
26.0
29.0
2.8
(1)
With nominal air flow; water flow outlet at 7ûC ; full load
CQH -- R 407C
Size 017 020 023 025 028 030
Working Range
Max. outdoor air temperature
(1)
ûC
45.0 41.5 44.0 42.0 41.5 39.5
Safety Device Settings
High pressure switch
(1)
High pressure safety valve
Low pressure switch
Barg
Barg
Barg
26.0
29.0
2.8
(1)
With nominal air flow; water flow outlet at 7ûC ; full load
SBH -- R 407C
Size 017 020 023 025 028 030 032
Working Range
Max. outdoor air temperature
(2)
ûC
42.5 39.5 42.5 40.5 38.5 41.0 39.0
Safety Device Settings
High pressure switch
(2)
High pressure safety valve
Low pressure switch
Barg
Barg
Barg
26.0
29.0
2.8
(2)
With nominal air flow; mixture flow outlet at 10ûC; full load
SLH -- R 407C
Size 017 020 023 025 028 030 032
Working Range
Max. outdoor air temperature
(2)
ûC
40.0 37.0 39.5 37.5 40.0 40.0 38.5
Safety Device Settings
High pressure switch
(2)
High pressure safety valve
Low pressure switch
Barg
Barg
Barg
26.0
29.0
2.8
(2)
With nominal air flow; mixture flow outlet at 10ûC; full load
SQH -- R 407C
Size 017 020 023 025 028 030
Working Range
Max. outdoor air temperature
(2)
ûC
42.0 39.0 40.5 38.5 39.0 36.5
Safety Device Settings
High pressure switch
(2)
High pressure safety valve
Low pressure switch
Barg
Barg
Barg
26.0
29.0
2.8
(2)
With nominal air flow; mixture flow outlet at 10ûC; full load
