HIMOD−C
60 Hz
CONFIGURATION MODELS
FLA
(A)
LRA
(A)
RESIDUAL−CURRENT CIRCUIT BREAKERS
Inn = 0.3A (400V)
3ph / 208−230V
(F): Cooling
27 – 45 C
8,9 35,4 16A
(F):
Cooling
Fan(s)
55 – 65 – 80 – 85 C
17,8 70,8 25A
(F+C): Cooling + Electrical heating
27 – 45 C
24,3 35,4 32A
(F+C):
Cooling
+
Electrical
heating
Fan(s) + heating
55 – 65 – 80 – 85 C
48,6 70,8 50A
(F+C+H): Cooling + Electrical
heating + Humidity
27 – 45 C
33,3 33,3 63A
heating + Humidity
Fan(s) + heating + humidification
55 – 65 – 80 – 85 C
57,6 57,6 80A
3ph / 380V
(F): Cooling
27 – 45 C
4,9 20,4 10A
(F):
Cooling
Fan(s)
55 – 65 – 80 – 85 C
9,7 40,8 16A
(F+C): Cooling + Electrical heating
27 – 45 C
13,8 20,4 16A
(F+C):
Cooling
+
Electrical
heating
Fan(s) + heating
55 – 65 – 80 – 85 C
27,5 40,8 32A
(F+C+H): Cooling + Electrical
heating + Humidity
27 – 45 C
22,8 22,8 40A
heating + Humidity
Fan(s) + heating + humidification
55 – 65 – 80 – 85 C
36,5 36,5 50A
3ph / 460V
(F): Cooling
27 – 45 C
4,0 16,0 10A
(F):
Cooling
Fan(s)
55 – 65 – 80 – 85 C
8,0 32,0 10A
(F+C): Cooling + Electrical heating
27 – 45 C
11,4 16,0 16A
(F+C):
Cooling
+
Electrical
heating
Fan(s) + heating
55 – 65 – 80 – 85 C
22,7 32,0 25A
(F+C+H): Cooling + Electrical
heating +Humidity
27 – 45 C
20,4 20,4 32A
heating +Humidity
Fan(s) + heating + humidification
55 – 65 – 80 – 85 C
31,7 31,7 40A
NOTES:
S The cables have to be sized in compliance with local standards and according to the type and characteristics (e.g. Amperes) of installation.
S The specific power the user−installed switch allows must be lower than 300,000 A
2
x s.
S Prescriptions on the differential relay required to the user:
S for special places (healthcare facilities, etc...) comply with the local regulations;
S For ordinary places, a low sensitivity is suggested (300 mA) coordinated with the value of the ground heater (IEC 364): Ra v 50/Ia (Art.
413.1.4.1, CEI 64−8);
S In case of frequent over−voltages with mains impulse, it is advisable to install a selective differential and to evaluate the need for adopting
other devices.
S (Models 90−10−12−14 U C only) The value of current (Full Load Ampere) is calculated considering electric heaters running at a capacity
of 17,55 kW, configuration F+C and F+C+H.
