HIMOD−C
3.3 − Extension hood
false ceiling
A B C D
27−45 C
1000 890 500 / 1200 30
55−65−80−85 C
1750 890 500 / 1200 30
90−10 UC
2050 890 500 / 1200 30
12−14 UC
2550 890 500 / 1200 30
3.4 − Extension hood with sound reduction car-
tridges (Over unit)
3.5 − Horizontal discharge hood (Over unit)
front back
A B C
27−45 C
1000 890 600/900
55−65−80−85 C
1750 890 600/900
