Liebert HPSE User Manual

Installation
9--4
Liebert HPS---PD--- 272965---20.11.2009
F i g . 1 7 --- SE 06-- 08-- 10-- 13-- 14W service area
CB D
A
BC DA
200 300 300 0
200 100 0 0
VERSION WITH FREECOOLING
VERSION WITHOUT FREECOOLING
E
700
700
E
B
C
F i g . 1 8 --- SE 06-- 08-- 10-- 13-- 14W evaporating unit wall installation
1050 (SE 06W)
1550 (SE 06W)
min. 500
1395 (SE 08--- 10--- 13--- 14W)
1895 (SE 08--- 10--- 13--- 14W)
AIR RETURN
AIR CON DITIONED
OUTSIDE AIR
800 (SE 06W)
min. 200
1000 (SE 06W)
1100 (SE 08--- 10--- 13--- 14W)
1300 (SE 08--- 10--- 13--- 14W)
AIR CON DITIONED
AIR RETURN
With freecooling option
Without freecooling option
