Liebert HPSE User Manual

Installation
9--10
Liebert HPS---PD--- 272965---20.11.2009
F i g . 2 4 --- Liebert HPSW (SE_W + HPSCxxA) suggested refrigerant connections
5mmax.
vertical
distance between
two syphons
Gas pipeline
(Sloping 1%)
NOTE:
Max. equivalent length for
refrigerant line A + B =10m
Gas pipeline
(Sloping 1%)
10 m max. horizontal equivalent length
Gas pipeline
(Sloping 1%)
SE_W
(Internal Unit)
7 m max. horizontal equivalent length
A
Syphons
(obligatory)
HPSC
(External Unit)
Gas pipeline
(Sloping 1%)
HPSC
(External Unit)
Gas pipeline
(Sloping 1%)
SE_W
(Internal Unit)
B
SE_W
(Internal Unit)
3mmax.
vertical distance
HPSC
(External Unit)
Liquid/gas pipeline
Liquid/gas pipeline
Liquid/gas pipeline
