BOLT
10. PARTS LIST
NO.
DESCRIPTION
SPECS
QTY
NO.
DESCRIPTION
SPECS
QTY
1
MAIN FRAME
1 38 speed + -Pulse 1
2
BASE FRAME
1 39 start/stop Pulse 1
3 Left Upright Frame 1 40 Control Board 1
4 Right Upright Frame 1 41 Computer bottom wire 1
5 Motor Base Frame 1 42 COMPUTER UP wire
1
6 Computer Frame 1 43 Rubber pad 2
7 Rubber Pad 4 44 magnet ring
Φ28*Φ16
*28
1
8 Rotating casing 2 45 Brown single wire 1
9
FRONT ROLLER
1 46 Bolt M8*25 1
10
REAR ROLLER
1 47 1 Screw M6 2
11 CYLINDER 1 48 Bolt ST4.2*55
4
12 5#ALLEN WRENCH 5mm 1 49 Bolt M6*45 1
13 Bolt M5*15 2 50 Bolt M6*65 2
14 DC Motor 1 51 Bolt M8*16 10
15 Running board 1 52
Bolt
ST4.2*20
4
16 Non slip mat 2 53
Bolt
M8*40 2
17 Inclined tube plug 2 54
Bolt
M10*70 2
18
MOTOR TOP COVER
1 55 Lock washer 8 7
19
MOTOR BOTTOM COVER
1 56 Bolt ST4.2*12
7
20 Side rail 2 57 Bolt M5*8 4
21 RIGHT BACK COVER 1 58 1 screw M8 4
22 LEFT BACK COVER 1 59 Bolt M8*30 1
23 Spring 2 60 Bolt ST4.8*25
4
24 Motor Bolt 1 61 Oil bottle 1
25 Power cord 1 62 Bolt ST4.2*19
6
26 Running Belt 1 63 Lock washer 5 2
27 Foot Pad 4 64 Lock washer 8 10
28
The annular convenient plug
B
2 65 Lock washer 6 3
29 Transport wheel 2 66 Lock washer 10 2
30 Wheel cover 2 67 Stand Lock washer 8 6
31 Stand power 1 68 Bolt M6*37 2
32 Switch 1 69 Bolt M6*35 8
33 Foam grip 2 70 Bolt M8*45 2
34 Bolt ST4.2*13 8 71 Safety key
1
35 Computer down cover 1 72 Elastic Cushion
4
36 Computer back cover 1 73 Bolt M8*42 1
37 Computer board 1 74 Lock washer 5 2
