LifeSpan EXER-11 User Manual

7
4. PARTS LIST
No Parts name Qty NO Specifications Qty
1 Main frame 1 25 Wire hole plug 4
2 Rear support tube 1 26 Tension control 1
3
Front bottom tube
1
27
Screw M5x20
1
4 Rear bottom tube 1 28 Washer D5 1
5 Seat tube 1 29 Screw M8×15 2
6 Handlebar 1 30 Washer D8 6
7 Cushion 1 31 Axis sleeve 4
8 Back seat frame 1 32 Revolving shaft 1
9 Rear handlebar 1 33 Nylon nut M8 2
10 Seat tube sleeve 1 34 Bolt M8×50 2
11 Knob 1 35 Tube cap 4
12 Curved washer D8 8 36 Screw M8x75 1
13 Nut M8 5 37 Tube cap 1
14L/R
Transport wheel cap
2
38
Screw M8x45
4
15 Screw T4.2×18 2 39 Washer D8 4
16 Rear bottom tube cap 2 40 Backseat 1
17 Absorber 1 41 Sensor 1
18 Foam handlebar 2 42L/R L&R crank 2
19 Tube cap 4 43L/R L&R pedals 2
20 Handle pulse 2 44L/R L&R nylon nut 2
21 Monitor 1 45 Spring pin 1
22 Seat 1 46 Revolving shaft sleeve 2
23 Washer D8 3 47 Foam handlebar 2
24 Nylon nut M8 3 48 Screw M8x40 4
