Lifetime 1270 - Step 1.2: Extend Top Pole

13
TOOLS AND HARDWARE REQUIRED FOR THIS PAGE
Slide the Top Pole (ALH) far enough out of the -IDDLE0OLE!,& so that it
does not obstruct the holes at the bottom of the Middle Pole. Then
attach the hardware indicated in the location shown.
SEC
1.2
1/2”
AAN (x1)
AOL (x1)
ABD (x1)
7!2.).'
Do not overtighten the Cap Nut. If the end of
the Bolt breaks through the plastic cap, call our
Customer Service Department. Exposed threads
on the end of the Bolt may cause serious injuries.
ALH
!,&
AOL
ABD
AAN
