Lifetime 1270 - Backboard to Pole Assembly

20
BACKBOARD TO POLE ASSEMBLY
SEC
3
Hardware shown at Actual Size
HARDWARE REQUIRED
!0' (x2)
5/16” x 3 1/4” Hex Bolt
AAC (x2)
5/16” x 1 3/4” Hex Bolt
ABD (x4)
5/16” Washer
ADQ (x2)
5/16” x 1” Screw
APK (x1)
v5"OLT
ABK (x4)
5/16” Nylock Flange Nut
APN (x2)
v&LANGE,OCK.UT
