Lifetime 1270 - Step 2.3: Position Pole Assembly on Base; Step 2.4: Secure Pole to Base

19
TOOLS AND HARDWARE REQUIRED FOR THIS PAGE
Place the Pole assembly on the ground with the crimped end of the
Top Pole (ALH) facing down. Position the vXv!XLE!*# under the
bottom slots of the "ASE!*- as shown, and step onto the Base so the
Axle snaps into the slots. Then rotate the Pole assembly upward so that
the vXv!XLE!*% snaps into the upper slots of the Base as shown.
SEC
2.3
BTS (x1)
1/2" (x2)
CII (x1)
Attach the Pole Braces (ALI) to the Bottom Pole (ALE) with the hardware
shown, and tighten all Pole to Base assembly hardware.
SEC

Note: Tip the system forward so the Pole rests on the ground. Do not stand
the system up until it is fi lled with either sand or water later in the assembly.
!
!*#
!*-
!*%
!*-
BTS
CII
ALE
ALI
ALI
3/16" (x2)
