-13-
4
4-7 1.6 -2.7 Gobo1
8-11 3.1 -4.3 Gobo2
12-15 4.7-5.9 Gobo3
16-19 6.3-7.5 Gobo4
20-23 7.8-9.0 Gobo5
24-27 9.4 -10.6 Gobo6
28-31 11.0 -12.2 Gobo7
32-35 12.5-13.7 Gobo8
36-39 14.1-15.3 Gobo9
40-43 15.7-16.9 Gobo10
44-47 17.3-18.4 Gobo11
48-51 18.8-20.0 Gobo12
52-55 20.4-21.6 Gobo13
56-59 22.0-23.1 Gobo14
60-73 23.5-28.6 Gobo1
Shake Slow-Fast
Speed
74-87 29.0-34.1 Gobo2
Shake Slow-Fast
Speed
88-101 31.4-39.6 Gobo3
Shake Slow-Fast
Speed
102-115 40.0-45.1 Gobo4
Shake
Slow-Fast
Speed
116-129 45.5-50.6 Gobo5
Shake
Slow-Fast
Speed
130-143 51.0-56.1 Gobo6
Shake
Slow-Fast
Speed
144-157 56.5-61.6 Gobo7
Shake
Slow-Fast
Speed
158-171 62.0-67.1 Gobo8
Shake
Slow-Fast
Speed
172-185 67.5-72.6 Gobo9
Shake
Slow-Fast
Speed
186-199 72.9-78.0 Gobo10
Shake
Slow-Fast
Speed
200-213 78.4-83.5 Gobo11
Shake
Slow-Fast
Speed
214-227 83.9-89.0 Gobo12
Shake
Slow-Fast
Speed
228-241 89.4-94.5 Gobo13
Shake
Slow-Fast
Speed
242-255 94.9-100 Gobo14
Shake Slow-Fast
Speed
5
Prism
0-63 0-24.7 Unused
Range
64-127 25-49.8 Prism1
128-191 50.2-74.9 Prism2
192-255 75.3-100 Prism1+Prism2
6
Prism Rotation
0 0 UnusedRange
1-63 0.4 -24.7
Angle linear adjustment
Three prism effect options: set the prism (prism 1, prism 2 or prism 1+2) in the 5th channel;
64-127 25.1-49.8 CCW，Fast → Slow
128-191 50.2-74.9 CW，Slow → Fast
192-207 75.3-81.2
208-223 81.6-87.5
224-239 87.8-93.7
240-255 94.1-100
Prism Macro
0-15 0-5.9 UnusedRange
DMX
Percentag
Function
Note
Slow → Fast Rotation，90° degrees back and forth
Slow → Fast Rotation，180° degrees back and forth
Slow → Fast Rotation，270° degrees back and forth
Slow → Fast Rotation，360° degrees back and forth
channel
To Next Page
