-4-
● Power supplies available
- 200~240V 50/60Hz(Optional:100~240V 50/60Hz)
- Power supply :
Electronic auto-ranging
● Power ： 400W PF0.987
Power connector: Neutrik power●
Data in/out:Locking 3-pin( 5-pin XLR Optional) ●
● SOURCE
- Lamp:Discharge short arc lamp with integrated reflector
- Brand 1: USHIO NSL 30
- Lamp power：300W
- Light source CCT: 7300 K
- ：Life expectancy 2000h
- luminous flux ：19000 lm
- ：Control Automatic and remote on/off
- Ballast: Electronic
● OPTICAL SYSTEM
Beam range ：
- 1.8° beam angle ,0.6° / 1.2° beam angle selection
Output lens diameter：φ150mm
Light output ：375000 lux @10m
CRI:8- 0
● DYNAMIC EFFECTS
Color
- ，14 colours + open Bi-direction rotation and rainbow effect
Static gobo wheel
- φ106 11 Gobos + open + 3 animations range ,Bi-direction
flow water.
Prism
- 、8 face prism 8 + 8 + 8 multilayer prism,multiple prism
combination effect, prism macro effect variable speed
Frost effet
- adjustable wash effect angle
Focus ：Motorized focus
Strobe
- 0.5-12 times per second, adjustable pulse strobe and
random strobe.
Dimmer
- 0-100％ linear adjustment
X/Y Travel 540°/270°：
X/Y Resolution 2.11°/1.05°：
X/Y Speed 2.7S/1.6S ：
●CONTROL AND PROGRAMMING
IP set
- RDM two-way data transmission,Remote reset DMX
address
Display ：
- The display panel adopts a 1.77-inch TFT screen
Intelligent control ：Display board can record
device’s using time , showdevice’s temperature, channel
data and software version .
Error alarm
-Automatic alarm for fixture failure
Software upgrade
- Upgrade with DMX
Protocols ：DMX512, RDM
Control channels :
- 14CH.16CH .16 PLUS,See the channel table for details
IP RATE:IP20
Safety Devices
- BIPOlar circuit breaker with thermal protection.
- Automatic break in power supply in case of
overheating or failed operation of cooling system.
●Cooling
- Forced ventilation with axial fans.
●Structure
- Heat-proof plastic+module pressing alloy materials.
●The vertical direction use hidden locking device, convenient
transportation and maintenance.
● CE Marking
- In conformity with the European Union Low Voltage
Directive 2014/35/EU and Electomagnetic compatibility
Directive 2014/30/EU.
● MECHANICAL SPECIFICATION
- Integrated foldable light hook design, more convenient
for disassembly and transportation
Lighting Size 335mm×210mm×477mm ：
Box Size 410mm×290mm×575mm (1set)：
： ， ：18.5kg- N.W. 15.4Kg G.W.
(2 sets - default)：- Flycase Size
660X500X720MM
N.W.: 30.8Kg ，G.W.：62.8Kg
(4 sets - optional)：- Flycase Size
820X685X720MM
N.W.: 61.6Kg ，G.W.：106.6Kg
