-16-
4
4-7 1.6-2.7 Gobo1
8-11 3.1-4.3 Gobo2
12-15 4.7-5.9 Gobo3
16-19 6.3-7.5 Gobo4
20-23 7.8-9.0 Gobo5
24-27 9.4-10.6 Gobo6
28-31 11.0-12.2 Gobo7
32-35 12.5-13.7 Gobo8
36-39 14.1-15.3 Gobo9
40-43 15.7-16.9 Gobo10
44-47 17.3-18.4 Gobo11
48-51 18.8-20.0 Gobo12
52-55 20.4-21.6 Gobo13
56-59 22.0-23.1 Gobo14
60-69 23.5-27.1 Gobo1
Shake
Slow-Fast
Speed
70-79 27.5-31 Gobo2
Shake
Slow-Fast
Speed
80-89 31.4-34.9 Gobo3
Shake
Slow-Fast
Speed
90-99 35.3-38.8 Gobo4
Shake
Slow-Fast
Speed
100-109 39.2-42.7 Gobo5
Shake
Slow-Fast
Speed
110-119 43.1-46.7 Gobo6
Shake
Slow-Fast
Speed
120-129 47.1-50.6 Gobo7
Shake
Slow-Fast
Speed
130-139 51-54.5 Gobo8
Shake
Slow-Fast
Speed
140-149 54.9-58.4 Gobo9
Shake
Slow-Fast
Speed
150-159 58.8-62.4 Gobo10
Shake
Slow-Fast
Speed
160-169 62.7-66.3 Gobo11
Shake
Slow-Fast
Speed
170-179 66.7-70.2 Gobo12
Shake
Slow-Fast Speed
180-189 70.6-74.1 Gobo13
Shake
Slow-Fast Speed
190-199 74.5-78 Gobo14
Shake
Slow-Fast
Speed
200-225 78.4-88.2 Fast-Slow
Rotation
226-229 88.6-89.8 Stop
230-255 90.2-100 Slow-Fast
Rotation
5
Prism
0-63 0-24.7 Unused Range
64-127 25-49.8 Prism1
128-191 50.2-74.9 Prism2
192-255 75.3-100 Prism1+Prism2
6
Prism Rotation
0 0 Unused Range
1-63 0.4-24.7
64-127 25.1-49.8 CCW
，
Fast → Slow
128-191 50.2-74.9 CW，Slow → Fast
192-207 75.3-81.2
208-223 81.6-87.5
224-239 87.8-93.7
DMX
Percentag
Function
Note
Three prism effect options: set the prism (prism 1, prism 2 or prism 1+2) in the 5th channel;
Angle linear adjustment
Slow → Fast Rotation，90° degrees back and forth
Slow → Fast Rotation，180° degrees back and forth
Slow → Fast Rotation，270° degrees back and forth
channel
To Next Page
