-19-
4
12-15 4.7 -5.9 Gobo3
16-19 6.3 -7.5 Gobo4
20-23 7.8 -9.0 Gobo5
24-27 9.4 -10.6 Gobo6
28-31 11.0 -12.2 Gobo7
32-35 12.5 -13.7 Gobo8
36-39 14.1 -15.3 Gobo9
40-43 15.7 -16.9 Gobo10
44-47 17.3 -18.4 Gobo11
48-51 18.8 -20.0 Gobo12
52-55 20.4 -21.6 Gobo13
56-59 22.0 -23.1 Gobo14
60-73 23.5 -28.6 Gobo1
Shake
Slow-Fast
Speed
74-87 29.0 -34.1 Gobo2
Shake
Slow-Fast
Speed
88-101 31.4-39.6 Gobo3
Shake
Slow-Fast
Speed
102-115 40.0 -45.1 Gobo4
Shake
Slow-Fast
Speed
116-129 45.5-50.6 Gobo5
Shake
Slow-Fast
Speed
130-143 51.0 -56.1 Gobo6
Shake
Slow-Fast
Speed
144-157 56.5 -61.6 Gobo7
Shake
Slow-Fast
Speed
158-171 62.0 -67.1 Gobo8
Shake
Slow-Fast
Speed
172-185 67.5 -72.6 Gobo9
Shake
Slow-Fast
Speed
186-199 72.9 -78.0 Gobo10
Shake
Slow-Fast
Speed
200-213 78.4 -83.5 Gobo11
Shake
Slow-Fast
Speed
214-227 83.9 -89.0 Gobo12
Shake
Slow-Fast
Speed
228-241 89.4 -94.5 Gobo13
Shake Slow-Fast
Speed
242-255 94.9-100 Gobo14
Shake
Slow-Fast Speed
5
Prism
0-63 0-24.7 Unused
Range
64-127 25-49.8 Prism1
128-191 50.2 -74.9 Prism2
192-255 75.3-100 Prism1+Prism2
6
Prism
Rotation
0 0 Unused
Range
1-63 0.4 -24.7
64-127 25.1-49.8 CCW，Fast → Slow
128-191 50.2 -74.9 CW，Slow → Fast
192-207 75.3 -81.2
208-223 81.6 -87.5
224-239 87.8 -93.7
240-255 94.1-100
7
Prism Macro
0-15 0-5.9 Unused Range
16-55 6.3 -21.6
56-95 22.0 -37.3
96-135 37.6-52.9
136-175 53.3 -68.6
DMX
Percentag
Function
Note
Fast→Slow,From fast to slow,8 prism free switch
Fast→Slow,From fast to slow,8 prism+24 prism at the same time free switch
Fast→Slow,From fast to slow,24 prism free switch
Fast→Slow,8 prism + 24 prism to free switch from fast to slow
Slow → Fast Rotation，90° degrees back and forth
Slow → Fast Rotation，180° degrees back and forth
Slow → Fast Rotation，270° degrees back and forth
Slow → Fast Rotation，360° degrees back and forth
Three prism effect options: set the prism (prism 1, prism 2 or prism 1+2) in the 5th channel;
Angle linear adjustment
channel
To Next Page
