OVERALL SPECIFICATIONS
Standard Carrier Frequencies (IR) 2.06/2.54 MHz
Frequency Stability ± 3%
Signal-to-Noise Ratio > 73 dB
Dynamic Range > 73 dB
Frequency Response 100 Hz - 10 KHz
RECEIVER/AMPLIFIER SPECIFICATIONS
Receiver Type Superheterodyne
Receiver Sensitivity 6 µV for 60 dB S/N
Image and Spurious Rejection > 70 dB
Dimensions (W x D x H) 13.25” x 5.75” x 4”
Weight 5 lbs. with battery pack
Total Harmonic Distortion < 1% (Output = 1W)
Power Output 12W RMS
Speaker Type Standard Cone 4”
Speaker Load Impedance 4 Ohms
Adjustable Tone Controls ± 8 dB (100 Hz - 10 KHz)
Power Supply (UL Listed) 16V/2.0 A
Battery Power (1-year warranty) 12V NiMH Battery Pack
TRANSMITTER SPECIFICATIONS
REDMIKE and REDMIKE VC
Audio Distortion < 1 %
Built-in Microphone Unidirectional Electret
Battery Power (1-year warranty) 1 AA NiMH Rechargeable Sensing
Audio Input 3.5 mm
Dimensions (W x D x H) 0.9” x 1.0” x 3.5”
Weight 2.1 oz.
LT71 LightMic
Audio Distortion < 1 %
Built-in Microphone Unidirectional Electret
Battery Power (1-year warranty) 2 AA NiMH Rechargeable
Audio Inputs Mic Level 3.5 mm, Line Level 3.5 mm
Dimensions (W x D x H) 1.375” x .75” x 4.625”
Weight 3.7 oz.
REDMIKE Share Handheld Microphone
Audio distortion <1%
Built-in Microphone Uni-directional electret
Battery Power (1-year warranty) 2 AA NiMH Rechargeable
Battery Pack
Audio Input 3.5 mm
Dimensions (W x D x H) 8.25” x 1.3” x 1.3”
Weight (with batteries) 7.9 oz
SYSTEM SPECIFICATIONS
