Lightware UMX-TPS-TX120 - Factory Default Settings

11. Appendix  

Factory Default Settings
Parameter Setting/Value
Crosspoint settings
 
Audio I1 (Analog audio in 1)
Video port settings
HDCP Enabled
Autoselect Disabled
Emulated EDID on analog video inputs Factory #89: Universal Analog EDID
Emulated EDID on digital video inputs Dynamic #1: Copy EDID from connected sink device.
Test pattern mode Auto
Test pattern resolution 
Test pattern color (RGB code) #7F7F7F (grey)
 
Test pattern color (RGB code) on Testpattern input

#108020 (green)
Output signal type Auto
Output HDCP mode Auto
 Always on
Color space Auto
TPS mode Auto
Analog audio port settings (I1 and I5)
 0.00 dB (100%)
Balance 50 (center)
Network settings
IP address 
Subnet mask 255.255.255.0
Static gateway 
DHCP Disabled
 10001
 
HTTP port number 80
RS-232 settings
Control protocol 
Baud rate 
Parameter Setting/Value
Databits 8
Parity None
Stopbits 1
Operation mode Pass-through
 8001
Command injection port nr. - TPS 8002
IR port settings
Command injection status Enabled
 9001
 9002
Comm. inj. input port nr. - TPS 9003
Comm. inj. output port nr. - TPS 9004
GPIO port settings
Output level High
Direction Input




