10 | Attaching The Sliding Rod Cup December 2008
4. When you are completely happy with the position, firmly fix the cup by doing the
following:
• Push the pump several times, rapidly.
As you do so the air between the cup
and the glass will be removed and
the amount of the button showing will
gradually reduce.
• Keep pushing the pump until you can
no longer see the red line.
5. Attach two lil Buddy Jr. suction cups to the other side of the windshield. They can be
placed wherever you like, as long as they are shoulder width apart. So put them where
they feel most comfortable for you when lifting and moving the windshield. See figure
11.
6. Use one of the lil Buddy jr. suction cups and the handle on the Sliding Rod Cup, to turn
the windshield over and round so that the Sliding Rod Cup is closest to the car.
FIGURE 10 - PUMP CUP TO SECURE
FIGURE 11 - LIL BUDDY JR. PLACEMENT
After Sliding Rod Cup has been secured
to the windshield, check placement to
ensure proper rod location. If rod
movement occurred, repeat
steps 3 and 4.
lil BUDDY Jr. hand suction cups MUST BE
placed shoulder width apart for proper
windshield leverage.
