5. While using both lil Buddy Jr. suction cups, properly lift the windshield and gradually
move away from the vehicle to extend the sliding rod out for optimum clearance.
6. Gradually move around the front of the vehicle. Stay close to the vehicle as you go and
ensure you lift the windshield enough to clear the vehicle, but DO NOT lift it high.
7. When you get to the front tire on the other side of the vehicle, push back on the Swing
Arm so it moves around and away from the vehicle. Swing Arm should be positioned
approximatly where it was when Base Pivot Cup was installed. See figure 15.
8. Continue to push back on the arm to reduce the rod length. At the same time,
manoeuvre the windshield so it hovers above its final position. See figures 15 and 16.
December 2008 Using The Lil Buddy | 13
FIGURE 14 - WALK WINDSHIELD INTO POSITION
DO NOT hold windshield high
over the body.
Keep windshield close to vehicle while
walking around vehicle.
FIGURE 15 - WALK WINDSHIELD INTO POSITION
Push back on Swing Arm to move it
away from vehicle.
DO NOT allow windshield to drag the
glue on top drivers side of vehicle.
Swing Arm location must be correct for
proper windshield placement. See
troubleshooting section for additional
information.
