Set Parameters
Keep〖P〗depressed for 3 seconds. Display .
If the password is “000”, no password is needed to enter parameter setting status.
If the password is not “000”, it needs password to enter parameter setting status:
Display “PSd” + “password”.
Press〖▲〗or〖▼〗to set the “password” to the correct password.
Press〖S〗to confirm.
If the password is correct, enter parameter setting status, else exit.
After having entered parameter setting status, display the 1
st
parameter code + its value: “U10” + “value”.
In parameter setting status:
press〖S〗or〖P〗to select the parameter code (see Parameter code table in page 2).
Press〖▲〗or〖▼〗to set the value of the parameter.
Keep〖P〗depressed for 3 seconds to save the settings, and exit.
The setting status will exit if there is no key operation for 30 seconds, and the settings will not be saved.
Check incubated days and egg turned times
Press〖S〗and〖▲〗simultaneously, display incubated days: “day” + “valve” for 2 seconds.
Press〖S〗and〖▼〗simultaneously, display egg turned times: “cnt” + “value” for 2 seconds.
Control
Timer output R1
During【Timer R1 on time U41】, R1 energized.
During【Timer R1 off time U43】, R1 deenergized.
Temperature control
R5 and ex-SSR are the temperature control outputs.
PID control
When【Temperature control mode U73】= 0, PID control.
ON/OFF control
When【Temperature control mode U73】= 1, hysteresis control.
If Room temp. ≥ Temp. setpoint, R5 and ex-SSR deenergized.
If Room temp. ≤ Temp. setpoint –【Temperature hysteresis U16】, R5 and ex-SSR fully energized.
High temperature protection
When【Output R1 working mode U46】= 1 or 2:
If Room temp. ≥ Temp. setpoint +【High temp. protection start point U12】, R1 energized.
If Room temp. ≤ Temp. setpoint +【High temp. protection stop point U13】, R1 deenergized.
Note: after R1 is deenergized, it could be energized again after 3 seconds.
High/low temperature alarm
If Room temp. ≥ Temp. setpoint +【High temperature alarm point U15】, high temperature alarming:
alternatively display room temp. and “tHi”, R5 and ex-SSR off, beeping alarming.
If Room temp. ≤ Temp. setpoint +【Low temperature alarm point U14】, low temperature alarming:
alternatively display room temp. and “tLo”, beeping alarming.
If【Beep alarming U71】= 0, there is no beeping alarming.
Humidity control
If Room humidity ≥ Humidity setpoint, R2 deenergized.
If Room humidity ≤ Humidity setpoint -【Humidity hysteresis U50】, and R2 has stopped for【R2 delay protection time
U51】, R2 energized.
High humidity protection
When【Output R1 working mode U46】= 1 or 2:
If Room humidity ≥ Humidity setpoint +【High humidity protection start point U53】, R1 energized.
If Room humidity ≤ Humidity setpoint +【High humidity protection stop point U54】, R1 deenergized.
Note: after R1 is deenergized, it could be energized again after 3 seconds.
High/low humidity alarm
If Room humidity ≥ Humidity setpoint +【High humidity alarm point U56】, high humidity alarming:
alternatively display Room humidity and “HHi”, beeping alarming.
If Room humidity ≤ Humidity setpoint +【Low humidity alarm point U55】, low humidity alarming:
alternatively display Room humidity and “HLo”, beeping alarming.
If【Beep alarming U71】= 0, there is no beeping alarming.
Egg turning control
Output R3/R4 is universal timer output, although the function is designed for incubator egg turning.
Timer function for egg turning
During【Left turn R3 time U62】, display , R3 energized, R4 deenergized.
During【Right turn R4 time U64】, display , R3 deenergized, R4 energized.
One full egg turn = one left turn + one right turn. Egg turn counter counts the times of full egg turn.
