Page 30 of 44
Calibrating the WDPL
For the WDPL to function correctly you have to calibrate your system. This has to be done before using the WDPL.
You only have to do this once.
If the buttons are not activated for 15 sec., the clock function will appear in the display.
It is not necessary to repeat the calibration when changing batteries.
2. Measure the height from desk to floor.
If only one desk is connected, - go to point 4.
3. Press and then press , or to select desk.
If only one desk is connected it is not possible to select Desk ll or lll.
4. Press and hold and then press or to adjust the height in the display.
Example:
The display will switch from e.g. 68 to 69, 70, 71 etc. when is pressed and
held and then is pressed.
and e.g. 68 to 67, 66 etc. when is pressed and held and then is pressed.
5. When the wanted height is shown in the display, press and hold and
then . The reference height of the desk will now be stored in the control box.
When the reference height is stored, the digits will be switched off for 1 sec. and
back on again.
Display view:
Action:
1. Switch between [cm] and [inch]. Press and hold and then press
