Page Number - 2
Form 404031
• Do not exceed the stated maximum working pressure of the reel or of the lowest rated component in your system.
• Do not alter or modify any part of this equipment.
• Do not operate this equipment with combustible gas.
• Do not attempt to repair or disassemble the equipment while the system is pressurized.
• Make sure all fluid connections are securely tightened before using this equipment.
• Always read and follow the fluid manufacturers recommendations regarding fluid compatibility, and the use of protective
clothing and equipment.
• Check all equipment regularly and repair or replace worn or damaged parts immediately.
• Never point the dispensing valve at any part of the body or at another person.
• Never try to stop or deflect material from dispensing valve or leading connection or component with your hand or body.
• Always check equipment for proper operation before each use, making sure safety devices are in place and operating prop
-
erly.
• Always follow the pressure relief procedure after shutting off the pump, when chocking or servicing any part of the system,
and when installing, cleaning or changing any part of the system.
FAILURE TO HEED THE FOLLOWING WARNINGS INCLUDING MISUSE, OVER PRESSURIZING, MODIFYING PARTS,
USING INCOMPATIBLE CHEMICALS AND FLUIDS, OR USING WORN OR DAMAGED PARTS, MAY RESULT IN
EQUIPMENT DAMAGE AND/OR SERIOUS PERSONAL INJURY, FIRE, EXPLOSION, OR PROPERTY DAMAGE.
ASSEMBLY
Assemble reel as follows. Refer to SERVICE PARTS for part
numbers and location.
A. Assemble arbor and ratchet casting (237769) to support
assembly (237656) with hex head screws (50014) and
secure with hex nuts (51022).
B. Lubricate V-ring seal (237671) and assemble onto arbor
and ratchet casting (237769) with lip facing away from
arbor ratchet.
C. Assemble power spring assembly (248494) onto arbor and
ratchet casting (248494) until spring canister bottoms on
arbors shoulder.
D. Lubricate V-ring seal (237673) and assemble onto arbor
and ratchet casting (237769) with lip facing toward spring
canister.
E. Assemble axle assembly (242000) to sheave assembly
(237771) and secure with standoffs (237780).
F. Assemble axle and sheave assembly to reel by sliding the
axle assembly (242000) through the bearings in the arbor
and ratchet casting (237769) and securing with washer
(48217) and Tru-arc (68424).
Note:
Shim as required using shims (48385) between
washer (48217) and arbor and ratchet casting (237769) to
eliminate axle end play.
G. Assemble outboard axle assembly (237781) to standoffs
(237780) and secure with nuts (51412).
H. Rotate sheave assembly (237771) and align mounting
holes with mating holes in power spring canister (248494)
and secure using carriage bolts (237738), carriage bolt
(237739) and nuts (51412). Note: The carriage bolt
(237739) (.875 long) must be assembled in hole adjacent
to pawl pin on power spring assembly.
I. Assemble rollers onto 5/16” diameter pins in the order il
-
lustrated on page (6). Hold in place while inserting the four
5/16” washer head bolts through the assembly and secure
with four 5/16” washer head nuts. Assemble roller
outlet arm assembly onto three of the bolts (50014) and
secure using three nuts (51022).
J. Assemble swivel assembly(84679) in axle assembly
(242000) and tighten.
K. Assemble swivel outlet
adapter (242015) into the axle
assembly (242000) and secure.
L. Assemble hose clamp
(272382) to sheave assembly
(237771) with carriage bolt (237738) and secure with nut
(51010).
M. Assemble pawl (237683) to pawl pin on spring canister
(248494) and secure with washer (48327) and Tru-arc
(66316).
