Repair parts list (non-common parts)
Model Model Model Model Model Model
85247 85480 85481 85482 85483 274055
Item no. Qty. Description (120 lb) (120 lbs) 60 lbs) (400 lbs) (5 gal.) (400 lbs)
16 1 Plunger link rod 270648 270648 270614 270645 270641 270614
20 1 Reciprocating tube 275018 275018 275022 275158 275010 275022
56a 1 Housing tube 275191 275191 275190 275192 275189 275190
70 1 Flow control valve 270693 270693 270693 270693 270693 270693
73 1 Solenoid valve cartridge 270678 270678 270678 270678 270678 270678
77 1 Pressure reducing valve 270692 270692 270692 270692 270692 270692
79 1 Solenoid cable assembly None None None None None 273502
1)
Included in 275383 Soft Parts Kit
2)
The inlet strainer fits all FlowMaster models
Repair kit selection chart
Converting series “A” to series “B” pumps
Series “A” service page needed for teardown
Series “B” service page needed for reassembly
Item no. Kit no.
1 to 8, 32, 36 to 52, 58 to 67 No kit – parts identical for series a and series b.
9
1)
, 10, 10a, 10b, 10c, 10d, 14 and15 275186 - Upper bushing & plunger kit
17, 18, 19, 19a, 21, 24, 25, 26 , 27 and 56b 275187 - Lower bushing & plunger kit
11, 12, 13a, 13b, 275376 Spacer 275188 Pivot pin/anchor kit
20 Reciprocating tube. See chart page 35 for series b
28, 29, 30, 30a, 30b, and 31 275381 - Housing Cover Kit
56a and 57 (pressed into 56a) Housing tube. See chart pg. 35 Series b
Repair kit 275383 Repair kit
1)
Item 9 is assembled to Item 10
25
