PT 1000
AO4
G0
S6
S2
S1 / S4
AI1
DO1
G0
DO2
G
DO3
G0
AI4
2.2 kΩ
1 kΩ
PT 1000
20
2022-11-28
lindab | installation
We reserve the right to make changes without prior notice
FireSystemPro Temperature sensor
Pro-DTS
Pro-DTS duct sensor measures the air temperature in ventilation and air handling installations. It can be used for a wide
range of applications and is suitable for all environments. Since the mounting bracket is made of a flexible material it closes
tightly against the duct.
Installation and wiring
The duct sensor is very easy to mount and has an adjustable insertion length. The terminal block for connecting the
analog input to a controller is located under the cover. The cover is easily removed from the base with a twist. The sensor
is designed so that the seal remains in the cover at all times and the cable gland is replaceable.
