10.3 Find a Mounting Spot
1. When determining the mounting position of the doorbell, consider
these factors:
2. Place the screw hole positioning card against the wall to mark the
position.
Check if you can reuse the existing holes and anchors on the wall or
door frame.
If you are drilling the mounting holes for the first time, the recommended
mounting height is 48" / 1.2 m from the ground.
To adjust the angel, use the 15° mounting wedge as a supplementary
mounting bracket.
160°
160°
---
----
Doorbell
Without 15° Mounting Wedge With 15° Mounting Wedge
Doorbell
1.4m(55")
1.78m(70")
0.2m(8")1m(40")
30
