Line 6 Helix Troubleshooting Instructions

Line 6 Customer Service
Helix Floor Expression Pedal
Troubleshooting Instructions Rev A
Document 90-20-0505
Line 6 Page 5 of 13 5/9/2017
Troubleshooting Instructions
1.) Using a Phillips head screwdriver, remove indicated screws and remove the bottom
panel (50-50-0093):
