9.1 LT360 Mechanical Specifications
Main System
Operation Mount in any orientation, Ta 0° to 40°C
Platter Cast & Machined Aluminum A356-T6
Base Cast & Machined Aluminum A356-T6
Bearing 5 Inch (125mm) Sealed Ball Bearing ABEC-1
Hub 4 Inch Diameter, 0.8 Inch Wall
Axial Load 1,000 lbs (900 kg) Max, Bidirectional
Radial Load 500 lbs (230 kg) Max
Drive System Irreversible Worm Drive
Scale Accurate Screen Printed 1 Degree
Chassis 16ga Steel
Drive System
Motor NEMA-23 Stepper Motor
Controller Bipolar, Microstepping, Microprocessor
Direction Either Counterclockwise or Clockwise
Shaft 0.375 Inch Dia, Steel 1040
Worm 0.75 Inch SAE 4340 Hardened Steel
Worm Gear 5.75 Inch SAE 65 Phosphor Bronze
Bearing Sealed Ball Bearings ABEC-3
Torque 49 N•M Standard Model, Programmable
Torque 76 N•M HiTorque Model, Programmable
Velocity 0.01 ... 3.0 RPM, Programmable
Acceleration 5 Acceleration Functions
Resolution 0.003125 Degree
Step Size 0.1 Degree Minimum
Backlash ±0.07 Degree Typical
Origin User Resettable
