Linhai ATV 500-D T3 EFI User Manual

CHAPTER 3 ENGINE LH500ATV-D T3 EFI SERVICE MANUA 19.0
CHAPTER 3 ENGINE PAGE. 3-
19
REF.
NO
ITEM
Type/SPECIFICATION
1
Type
Single Cylinder, 4-Storke, Liquid-cooled,
4 Valve, SOHC
2
Bore and stroke
87.5mm×82.0mm
3
Displacement
493ml
4
Compression ratio
10.2: 1
5
Lowest continuous idle speed with load
1400r/min±100r/min
6
Starting type
Electrical starting
7
Electrical
System
Ignition /
Ignition Timing
CDI Magneto ignition/BTDC10°1500r/min
EFI ECU Magneto ignition/BTDC10°1500r/min
Spark Plug/
Spark Plug Gap
DPR7EA-9 (NGK)/0.8mm-0.9mm
Magneto
Permanent Magnet AC Type
8
Combustion
System
Combustion Chamber
Triangle Combustion Chamber
Carburetion Type/Model
Vacuum Diaphragm Type/MIKUNI BSR36-129
Air Filter
Sponge Element Filter
Gasoline
RQ-90
9
Valve
System
Valve Type
SOHC/Chain Drive
10
Lubrication
System
Lubrication Type
Pressure & Splash
Oil Pump
Rotor Type
Filter Type
Full Flow Filter Screen
Oil Type
SAE10W-50/SN
11
Cooling
System
Cooling Type
Closed Coolant Circulation
Coolant Type
—35℃ Rust-resistant antifreeze
12
Drive
System
Clutch type
Wet, Auto-centrifugal
Operation Mode
Automatic(CVT)+Parking and Gear Shifting
Gears
2 Forward Gears + 1 Reverse Gear
Shift Type/Sequence
Hand Operation/L-H-N-R
(CVT) Gear Ratio
2.88-0.70
Transfer
Gear Ratio
Final Ratio
1.333(24/18, bevel gear)
Secondary
Ratio
1.952(41/21)
Gears
Low Gear:2.25(36/16) High Gear :1.35(27/20)
Reverse Gear:1.471(25/17)
Total
Low Gear:5.857, High Gear:3.514,Reverse Gear:3.828
13
Overall Dimension
610×568×519mm
14
Net Weight
70kg
15
Output type
Front and rear shaft output
16
Rotational Direction of Engine Output
Clockwise (from behind engine at forward gear)
Engine Specification

Linhai ATV 500-D T3 EFI Specifications

General

Brand	Linhai
Model	ATV 500-D T3 EFI
Category	Offroad Vehicle
Language	English
