LH40DA OWNER’S/OPERATOR’S MANUAL 18.0
14. SPECIFICATION
14-1
Dimensions & Capacities
L X W X H
2150X1160X1270 mm
84.6x 45.7x50 in
Seat height
900mm
35.4 inch
Wheel Base
1270 mm
50 in
Turn diameters
6500mm
256 in
Ground Clearance
240 mm
9.4 in
Dry Weight without battery
286kg
939lb
Front Rack
10kg
22 lbs
Rear Rack
20kg
44 lbs
Load Capacity(Combined Rider& Payload)
150kg
330 lbs
Tongue Weight
10kg
22 lbs
Tow Capacity
190kg
418.8 lbs
Drive System
Electric motor
48V PMSM
Front Tire
24X8-12
Rear Tire
24X8-12
Tire Pressure(front)
150 kPa
21.7 PSI
Tire Pressure(rear)
150 kPa
21.7 PSI
Brake System
Front Brake
Service Brake
Rear Brake
Hydraulic Disc
Parking Brake
All Wheel
Hydraulic Lock
Auxiliary Brake
Rear Brake
Hydraulic Disc
Suspension
Front
McPherson independent suspension
Rear
Twin-A arm independent suspension
shock absorber
Coil spring/oil damper
