Linksys AC1750 User Manual

28
Setting Up: Advanced
Linksys EA-Series
Example: Because each MAC filtering configuration is unique, the following
procedure uses the simplified example of setting up MAC filtering to allow one
wireless device access to the network.
TIP
You can also use MAC filtering to prevent specific PCs from
accessing your network by selecting Deny. However, it’s easier
to select Allow to permit only known devices than to exclude
unknown devices.
To set up MAC filtering to allow one wireless device access to your
network:
1. Log into Linksys Smart Wi-Fi. (See “How to connect to Linksys Smart Wi-
Fi” on page 7.
2. Under Router Settings, click Wireless. The Wireless page opens.
3. Click the MAC Filtering tab.
4. Select Enabled next to MAC Filters, then select Allow access for ONLY
the listed MAC addresses.
5. Click Add MAC Address, then enter the MAC address into the MAC Filter
List and click Save.

Linksys AC1750 Specifications

General

Brand	Linksys
Model	AC1750
Max Data Rate	1750 Mbps
Ethernet Ports	4 x Gigabit LAN, 1 x Gigabit WAN
USB Ports	1 x USB 3.0, 1 x USB 2.0
Memory	128 MB Flash, 256 MB RAM
Wireless Standards	802.11a/b/g/n/ac
Bands	2.4 GHz, 5 GHz
Wireless Speed	450 Mbps (2.4 GHz), 1300 Mbps (5 GHz)
Frequency Band	2.4 GHz, 5 GHz
Antennas	3 external antennas
Processor	dual-core
Security	WPA2 Personal, WPA2 Enterprise, WPA, WEP
Wi-Fi Technology	Dual-Band
Weight	1.43 lbs
