Linksys Compact Wireless-G User Manual

10
Chapter 4: Connecting the Compact Wireless-G Broadband Router
Hardware Installation for Connection to your Broadband Modem
Compact Wireless-G Broadband Router
4. Connect a standard Ethernet network cable from one of the Router’s numbered ports to your network PC or
Ethernet device.
5. Connect the AC power adapter to the Router's Power port. Then connect the other end to an electrical outlet.
Only use the power adapter supplied with the Router. Use of a different adapter can cause product damage.
Now that the hardware installation is complete, proceed to “Chapter 5: Configuring the Compact
Wireless-G Broadband Router.”
Figure 4-2: Connecting Your Network Devices
Figure 4-3: Connecting the Power
IMPORTANT: Make sure you use the power
adapter that is supplied with the Router. Use of a
different power adapter could damage the Router.
