Linksys E5600 User Manual

14
Your Internet cable is not plugged in message
If you get a “Your Internet cable is not plugged in” message when trying to set up your router:
•
Make sure that an ethernet or internet cable (or a cable like the one supplied with your router)
is securely connected to the yellow Internet port on the back of the router and to the
appropriate port on your modem. This port on the modem is usually labeled Ethernet.
•
Make sure that your modem is connected to power and is turned on.
If your internet service is cable, verify that the cable
modem’s CABLE port is connected to the coaxial cable
provided by your ISP.
If your internet service is DSL, make
sure that the DSL phone line is
connected to the modem’s DSL port.
•
If your computer was previously connected to your modem with a USB cable, disconnect the
USB cable.
•
Install the router again.

Linksys E5600 Specifications

General

DSL WAN	No
Ethernet WAN	Yes
WAN connection type	RJ-45
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Channels quantity	2 channels
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	1200 Mbit/s
WLAN data transfer rate (first band)	866 Mbit/s
WLAN data transfer rate (second band)	300 Mbit/s
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Ethernet LAN interface type	Gigabit Ethernet
Mobile network generation	-
Ethernet LAN (RJ-45) ports	1
Product type	Tabletop router
Product color	Black
LED indicators	LAN, Power, Status
Antennas quantity	4
Internal memory	128 MB
Processor cores	2
Processor frequency	880 MHz
Output current	1 A
Output voltage	12 V
AC input voltage	100 - 240 V
Power source type	DC
AC input frequency	50 - 60 Hz

Weight and Dimensions

Depth	91 mm
Width	220 mm
Height	235.7 mm
Weight	861.8 g
