Page 22 of 33 FA69388–2 English

Jun 2013

How To Use the Parallel I/O Option

Linx 5900 & 7900

3 Highlight one of the events in the list, and then press the OK key to select that event

and return to the Event page.

Figure 34. Edit Outputs: Outputs page

In Figure 34, Output 1 is activated if the printer status is “IDLE”.

Duration

The output signal can be a single pulse, a series of pulses, or a continuous level. You can use

a different type of signal for each output.

1 Press the Duration key then the Select key to see the available signal types.

Figure 35. Duration: Type page

69449

69450
