Lipper Ground Control 3.0 - Bottom of Jack Motor Override

Rev: 09.02.21 Page 9 CCD-0004395
Bottom of Jack Motor Override:
Tools needed:
⁄
” drive ratchet and extension,
⁄
” socket
1. Find the port on the bottom of the jack motor (Fig. 15A).
2. Remove the rubber plug (Fig. 16A).
3. Insert the
⁄
” socket into the port (Fig. 17).
4. Turn override until the jack extends or retracts to desired position.
5. Insert the rubber plug back into the port after extension/retraction is complete.
Fig. 15
A
Fig. 16
Fig. 17
A
