Rev: 07.30.18 Page 6 CCD-0001522
Operation
Prior to Operation
The landing gear system should only be operated under the following conditions:
1. The trailer is parked on a reasonably level surface and the tires are chocked.
2. Make sure all persons, pets and property are clear of the trailer while the landing gear system is in
operation.
3. Make sure battery is fully charged.
Extending Landing Gear
1. Extend both landing gear to the ground by pulling the quick release bolt-on pull pins.
NOTE: If the front of the trailer is above level, do not extend the inner legs to the ground. The trailer cannot
be leveled if the front is already above level when released from the tow vehicle.
2. Make sure the bolt-on pull pins are engaged.
3. Push EXT side of the landing gear switch.
4. Unhook trailer from tow vehicle.
5. Raise landing gear to desired height.
Retracting Landing Gear
1. Push RET side of landing gear switch.
2. Lower trailer onto tow vehicle.
3. Once trailer is secured, make sure the trailer is latched.
4. Fully retract both landing gear.
NOTE: Be sure to hold down the switch until both landing gear are fully retracted before pulling the bolt-
on pull pins.
5. Pull the bolt-on pull pins and slide the inner legs into the outer landing gear legs.
6. Make sure the bolt-on pull pins are engaged upon completion.
NOTE: In the event the landing gear become out-of-sync, fully retract them to synchronize the landing
gear again.
Never attempt to operate the system without the footpad properly secured or severe product damage,
serious personal injury or death may occur. Electric landing gear is designed for vertical operation.
Excessive side loads may cause damage to the landing gear. The bolt-on pull pin MUST be inserted fully
through both sides of the tube prior to use. Do not use landing gear to service the trailer or change tires.
Retract landing gear completely prior to moving the trailer.
