Step with Control Unit
1. After the installation is complete and with the entrance door open, turn the step override switch to the
off position.
NOTE: Some steps are not equipped with a step override switch. They are activated only with a door switch.
2. Close the door. The step should retract and lock in the up position. If equipped with an under-step
light, the light will be off.
3. Open the door. The step should extend and lock in the down position. If equipped with the under-step
light, the light will be on.
If so equipped, the under-step light operation is as follows: The light is on when the step is extended and
the light is off when the step is retracted.
NOTE: In the event the coach door/screen door is left open, the light will turn off after five minutes.
4. If the step is equipped with a step override switch, turn it to the on position. The step should remain in
the extended position with the under-step light off when the door is closed.
5. With the step override switch turned on, the step extended and the entrance door closed, turn the
vehicle ignition on. The ignition override system will go into effect and the steps will automatically
retract.
NOTE: If the yellow wire from the four-way connector is not connected to an ignition power source, the
ignition safety system will be inoperative and the step will remain in the extended position. In this
case, the step override switch MUST be turned off for the step to retract.
6. Turn the vehicle ignition off and open the door. The step will extend and lock in the down position.
This is the Auto Extend feature. When the vehicle ignition is turned on, the step will activate with the
door movement, regardless of the step override switch position.
Operation
Stepping on a partially extended step may cause damage to the step frame. Do not use the step
until the step is fully extended.
If the vehicle is driven with the step in the extended position, product and/or property damage may occur.
