Rev: 09.15.20 Page 12 CCD-0001531
Plumbing Diagram - 6-Point Level Up
Leveling Jack
Leveling
Mid Jack
Retract Valve Block
Leveling
Mid Jack
Leveling Jack
Extend Valve Block
Pressure Switch
Valve
Power Unit
Landing Gear
Valve
Orange
Black
