Rev: 09.15.20 Page 4 CCD-0001531
1. Make sure the 5th Wheel is parked on a reasonably level surface.
2. Clear all jack landing locations of debris and obstructions. Locations should also be free of depressions.
3. When parking the 5th Wheel on extremely soft surfaces, utilize load distribution pads under each jack.
4. Make sure the battery of the 5th Wheel is fully charged or that the 5th Wheel is plugged into shore
power prior to attempting to operate the system.
Note: Level-Up requires a minimum of 12V DC from the battery for proper operation.
Prior to Operation
The leveling system shall only be operated under the following conditions:
1. The trailer is parked on a reasonably level surface.
2. Make sure all persons, pets and property are clear of the trailer while the Level-Up LCD 5th Wheel
Leveling system is in operation.
3. Make sure the battery of the trailer is fully charged or that the trailer is plugged into shore power prior
to attempting to operate the system. The automatic leveling system requires a minimum of 12V DC
from the battery for operation.
Operation
Basic Jack Operation
1. Landing Gear Jacks
A. Landing gear jacks can be operated any time the system is on, but not in AUTO MODE. Press the
FRONT button (Fig. 1G), so that both the front or landing gear jacks can be extended.
B. If the touch pad is put in the RETRACT mode, indicated by the orange illuminated LED next to the
RETRACT button (Fig. 1D), the front jacks can be retracted together by pressing the FRONT button.
2. Level-Up Jacks
A. The Level-Up jacks operate when “AUTO MODE” is activated or the touch pad is in “MANUAL
MODE”.
B. Once the system is in “MANUAL MODE”, press the REAR button (Fig. 1J) to extend all Level-UP
jacks at the same time.
Note: Manual and Auto modes can be selected through the LCD menu by using the Up and Down Arrow
buttons, then press ENTER to select the desired mode
C. Press the LEFT or RIGHT buttons (Fig. 1H or 1I) to operate Level-Up jacks on the left (road) or right
(curb) side of the trailer, respectively.
A uid leak within a highly pressurized hydraulic system can cause serious skin-penetrating injuries.
Wear appropriate Personal Protective Equipment (PPE), such as long sleeves, gloves, protective
eyewear or a full face shield, when performing service or maintenance to the 5th Wheel.
The “CAUTION” symbol above is a sign that a safety risk is involved and may cause
personal injury and/or product or property damage if not safely adhered to and within the
parameters set forth in this manual.
Moving parts can pinch, crush or cut. Keep clear and use caution.
Preparation
